CPG2500高精度压力指示仪- 详细介绍：
Precision pressure indicator
1- or 2-channel version
Model CPG2500
Data sheets showing similar products and accessories:
Calibration software WIKA-CAL; see data sheet CT 95.10
Pressure supply case, filling tube; see data sheet CT 91.41
Precision pressure reducing valve, volume displacer; see data sheet CT 91.42
Precision pressure indicator model CPG2500
Applications
■ Factory calibration laboratories
■ Calibration service companies and service industry
■ Research and development laboratories
Special features
■ Measuring ranges up to 0 ... 700 bar / 10,000 psi (up to
two separate internal precision sensors possible)
■ Pressure type positive and negative gauge, absolute
pressure and also differential pressure possible via two
sensors
■ Precision down to 0.003 % IS (IntelliScale)
■ Accuracy down to 0.01 % IS (IntelliScale)
Description
Application
The CPG2500 is a modular pressure measuring instrument,
incorporating up to two high-precision pressure sensors (in
two separate channels) and a barometric reference as an
option.
Due to a DKD/DAkkS certified accuracy of the entire
measuring chain of 0.01 % (optional 0.01 % IS-50), it is
predominantly used as a factory/working standard for the
verification and/or calibration of the widest range of pressure
measuring instruments.
Functionality
A colour touchscreen, combined with a user-friendly menu,
guarantees the maximum ease of operation and all this
is available in a number of different languages. Various
functions, such as min/max memory, pressure rate, tare or
differential pressure measurement via two sensors, ensure
that this precision pressure measuring instrument can be
used for many different applications.
Software
WIKA-CAL calibration and documentation software makes
calibrating any type of pressure measuring instrument easy
and enables the simple production of calibration certificates
or the customer can create his own test programs, e.g. with
the help of LabVIEW® software.
Complete test and calibration systems
On request, complete mobile or stationary test systems
can be manufactured. For integration into existing systems,
RS-232, Ethernet, IEEE-488.2 (as an option) interfaces or an
optional analog output of DC 0 ... 10 V are available.
WIKA data sheet CT 25.02
